ENGLISH
15. Press " Confirm " after entering the password. 7. Wind the pipes continuously.
8. The refrigerant pipes must be provided with a separate insulation in the final part which is
connected to the condensing unit.
Note:
The power cable and the wire communication may not be the inverted.
The drain hose must be isolated at the discharge end
9. Wall mounting of the indoor unit
Once the pipe block and the cables are fixed together insert the block through the hole previously
−
drilled on the wall to be crossed .
Fasten the indoor unit , through the appropriate hooks, to the fixing bracket previously locked to
−
the wall.
− Ricoprire the spaces between the pipes and between pipes and holes with the sealing rubber.
16. Select and connect to the "Smart Life-xxx" network. Once connected, return to the App. If the
− Fix the pipes in the wall crossed or arrange an aesthetic containment duct fixed to the wall and
device has been added successfully will be a message on the Home page, after that you can click on
then pass the pipes inside .
the air conditioner for operations.
− Check that the indoor unit is securely locked to the support bracket and then securely fixed to the
wall.
Indoor
Wall pipe
The drain hose must not be overly covered to avoid blockage.
Note:
The drain pipe must follow the inclination of the hole in the wall as shown in the figure.
TEKNO POINT ITALIA S.R.L. - VIA DELL'ARTIGIANATO 5 - 30020 MARCON (VE) – ITALY TEKNO POINT ITALIA S.R.L. - VIA DELL'ARTIGIANATO 5 - 30020 MARCON (VE) – ITALY
COMMERCIALE@TEKNOPOINT.COM – WWW.TEKNOPOINT.COM COMMERCIALE@TEKNOPOINT.COM – WWW.TEKNOPOINT.COM
MUI_UNITÀ INTERNA DELFIN_Ita_Eng_Fra_Deu_SKY/Rev.00/Data 03.06.2020 MUI_DELFIN_Ita_Eng_Fra_Deu_SKY/Rev.00/Data 03.06.2020
Connection Drain
pipe hose
Indoor power cord
Outdoor
Sealing gum
47 56
Tape
Upper hook
Lower hook
ENGLISH
69
