Tekno Point DELFIN DLF-09 Benutzer- Und Installationshandbuch Seite 59

Buttons on remote controller
Button
• In non-auto mode, press this button to increase the set temperature;
• Press and hold down this button for more than 0.5 seconds, set the temperature to change quickly, the °C(°F) icon is displayed all the time during
the process, the temperature upper limit is 31°C(88°F).
Button
• In non-auto mode, press this button to decrease the set temperature;
• Press and hold down this key for more than 0.5 seconds, set the temperature to change rapidly, the °C(°F) icon is displayed all the time during
the process, the default temperature limit is 16°C(61°F).
15. Press " Confirm " after entering the password.
FAN button
• Press this button to set fan speed circularly: auto, quiet, fan1, fan2, fan3, fan 4, fan 5, turbo, stepless speed.
• Dry mode can only be set to low fan speed.
• No turbo fan speed under auto mode.
• No quiet fan speed under fan mode.
• Under auto fan speed, remote control display
Note:
In the stepless speed mode:
• Press the / button to modify the fan speed setting value.
• Long press / key 0.5 second after the rapid change of fan speed , digital fan speed display;
• Press FAN button to switch to other fan speeds during 5s timing, press FAN button again to enter stepless speed after 5s timing.
16. Select and connect to the "Smart Life-xxx" network. Once connected, return to the App. If the
device has been added successfully will be a message on the Home page, after that you can click on
ECO/SC button
the air conditioner for operations.
In the state of cooling mode, press "ECO/SC" button, to select ECO function, LCD display icon"ECO".
• Switch modes cancels ECO function. Turn off remote control and start again, ECO function reserved;
• The default fan speed is auto fan speed, the fan speed and setting temperature is non-adjustable.
• Sleep and ECO function cannot start at the same time.
Note:
• Long press the "ECO/SC" button in any state, the remote control display "SC" and enter the off state. Remote control sends self-cleaning
information.
• Under the SC state, turn on the machine by remote to exit SC state.
TIMER button
• Timing time range 0.5~24 hours, timing scale 0.5 hour.
• Press the TIMER button to set the timing on, LCD display "0.0", "h ON" flashing, After 5s, no operation default no timing. Timing time can be
adjusted within 5s by pressing " " or " " button. After setting the timing time, press the TIMER button to determine the timing time. When
adjusting the timing, long press for more than 0.5 seconds " " or " ", button, time setting changes quickly.
• Press the TIMER button to set the timing off. The setting method refers to the timing on.
WIFI button
• Press this button to turn on or turn off WIFI function.
• Press this button more than 2s to enter WIFI configuration mode.
TEKNO POINT ITALIA S.R.L. - VIA DELL'ARTIGIANATO 5 - 30020 MARCON (VE) – ITALY
• For more details, please see for Smart APP user manual.
, fan speed display circulary between grid 1 to 5.
COMMERCIALE@TEKNOPOINT.COM – WWW.TEKNOPOINT.COM
MUI_DELFIN_Ita_Eng_Fra_Deu_SKY/Rev.00/Data 03.06.2020
47
ENGLISH
59
