6. Using the wheelchair

After adjusting the wheelchair to your personal needs, familiarize yourself
with the control functions.

6.1. General functions

22.
Light
Use this button to switch on the active lighting system of your wheelchair
when darkness falls or when travelling through dark areas such as tunnels.
This will make you more visible to other traffic (fig. 22).

Warning indicators

Press this button to switch on the warning indicators in emergency
23.
situations, such as inability to move the wheelchair. All four indicator
lights will flash and signal other traffic that your wheelchair is disabled
(fig. 23).
Indicators (left/right)
Use this buttons (fig. 24) to switch on the left or right indicators of your
wheelchair to signal other traffic that you wish to change your direction
of travel to the left or right. Press the button again to switch off the
24.
indicator.
Battery status display
The battery status display (fig. 25) shows the charge status. If the display
is in the green range, the battery is sufficiently charged. If the display is
in the red range, the wheelchair can only be used for a short distance
and the battery should be charged as soon as possible (see charging
procedure).
25.
84
ON/OFF button
Press this button to switch on the wheelchair (fig. 26).
Display of mode
The mode display shows the preselected mode. Settings from 1 to 5 LEDs
are available. The modes indirectly define the maximum available speed
when the joystick is moved, i.e. in mode 5 the highest maximum speed is
available and in mode 1 the lowest (fig. 27).
Setting the mode
Press these buttons to change the mode, i.e. increase (right) or reduce
(left) the maximum available speed. The speed is controlled by movement
of the joystick (fig. 28).
Horn
Press this button to sound the horn (fig. 29).
Bischoff & Bischoff GmbH | 2024 - 03 - 21– Revision: 2
Taiga
Electric Wheelchair |
26.
27.
28.
29.
