37
Re-install Plastic Caps previously uninstalled in Step 33a.
SEAT BELT INSTALLATION
A)
38
A) Slide the Seat all the way backwards.
B) Thread the Seat Belt through Seat Belt cut outs on the Flight Seat.
39
Align the Seat Belt mounting plates with the threaded inserts on the bottom of the Flight Seat. Bolt
through and secure with 2 x M8 Bolts and Washers.
Video Instruction: bit.ly/nlrbuild
B)
Repeat
on Other
Side
25
PARTS:
• • NIL
PARTS:
• • 1 x Seat Belt
PARTS:
• • 2 x M8 16mm Sockethead Bolts
• • 2 x M8 Washers
