A) Align the mounting slots on the Telescoping Outer Arm with the threaded inserts on the Flight Arm.
B) Bolt through and secure with 4 x M8 Bolts and Washers.
A)
17
A) Align the threaded inserts on the Telescopic Inner Arm with the mounting slot on the Telescoping Outer Arm.
B) Bolt through and secure with 2 x M8 Bolts and Washers.
A)
18
A) Align the mounting slots on the Mouse Plate with the threaded inserts on the Telescoping Inner Arm.
B) Bolt through and secure with 4 x M8 Bolts and Washers.
B)
B)
B)
Tip: The Flight and Mouse
Plates are interchangeable
which allows them to be
mounted on both sides.
17
Video Instruction: bit.ly/nlrbuild
PARTS:
• • 1 x Telescoping Outer Arm
• • 4 x M8 16mm Sockethead Bolts
• • 4 x M8 Washers
PARTS:
• • 1 x Telescoping Inner Arm
• • 2 x M8 16mm Sockethead Bolts
• • 2 x M8 Washers
PARTS:
• • 1 x Mouse Plate
• • 4 x M8 16mm Sockethead Bolts
• • 4 x M8 Washers
