Next Level Racing FLIGHT SEAT PRO Montageanleitung Seite 32

support@nextlevelracing.com
56
Install the HOTAS Mount Assembly to the H Frame. Please refer to Step 24 to 27 for HOTAS Mount
Assembly.
A)
57
A) Align the Flight Arm Assembly with the threaded inserts on the Motion V3 Mounting Arm.
B) Bolt through and secure with 4 x M8 Bolts and Washers. Repeat the same for the Mouse Plate Assembly.
58
Your setup is complete.
B)
Repeat
on Other
Side
32
PARTS:
• • NIL
PARTS:
• • 8 x M8 16mm Sockethead Bolts
• • 8 x M8 Washers
PARTS:
• • NIL
