MOTION PLUS PLATFORM

LOWER FLIGHT ARM ASSEMBLY

(RECOMMENDED FOR COLLECTIVES)
43
Uninstall the Bolts and Washers securing the Flight Arm Assembly to the Frame and remove it.
A)
44
A) Align the mounting holes on the Flight Arm Assembly with the threaded inserts on the bottom rail of the Frame.
B) Bolt through and secure with 2 x M8 Bolts and Washers previously uninstalled in Step 43.
INSTALLATION
B)
27
Video Instruction: bit.ly/nlrbuild
PARTS:
• • NIL
PARTS:
• • NIL
