Next Level Racing FLIGHT SEAT PRO Montageanleitung Seite 23

A)
31
A) Uninstall the Swivel Flight Arm Assembly, and the HOTAS Centre Pole Assembly from the Frame of the Flight Stand Pro. A) Uninstall the Swivel Flight Arm Assembly, and the HOTAS Centre Pole Assembly from the Frame of the Flight Stand Pro.
B) Uninstall the Mouse Plate Assembly, and the HOTAS Centre Pole Assembly from the Frame of the Flight Seat Pro. B) Uninstall the Mouse Plate Assembly, and the HOTAS Centre Pole Assembly from the Frame of the Flight Seat Pro.
32
Uninstall 2 x Rear Castor Wheels and Square Washers from the Flight Stand Pro Assembly.
A)
33
A) Uninstall 4 x Bolts and Washers securing the Steel Safety Caps to the Flight Seat Pro Frame. Remove the Plastic Caps.
B) Uninstall the 2 x Steel Safety Caps.
Video Instruction: bit.ly/nlrbuild
B)
Note: The parts uninstalled
in this Step are based on
a recommended setup
and can be left installed
according to preference.
B)
23
PARTS:
• • Flight Stand Pro Assembly
• • Flight Seat Pro Assembly
PARTS:
• • NIL
PARTS:
• • NIL
