Loosen the Shoulder Bolts and change the Pedal Plate Assembly to your desired Height, Position and
Angle. Retighten the Shoulder Knob to lock in place.
BACKREST ADJUSTMENT
30 °
14
Loosen the 2 Bolts each side that secure the backrest to the Frame. Change to desired angle and
retighten the bolts to secure in place.
SEAT ADJUSTMENT
15
Loosen the Shoulder Knob and change the seat angle to desired position and retighten the bolts to
secure in place.
PEDAL ADJUSTMENT
40 °
