Next Level Racing FLIGHT SEAT PRO Montageanleitung Seite 30

support@nextlevelracing.com
50
Align the Motion V3 unit with the mounting holes on the Frame.
51
Bolt through and secure with 6 x M8 Bolts and Washers.
52
Align the threaded inserts at the bottom of the H Frame installed on the Flight Seat with the mounting
slots on the Motion V3 Platform.
WARNING: The NLR Motion V3 is
heavy and will require 2 people to
install the setup.
Repeat
on Other
Side
30
PARTS:
• • NIL
PARTS:
• • 6 x M8 55mm Sockethead Bolts
• • 6 x M8 Washers
PARTS:
• • NIL
