Important information

VECTRON L 02.120/160/210 DUO
burners are designed for the combustion
of extra-light fuel oil in accordance with
national standards:
A: ÖNORM C1109: standard or low
sulphur
BE: NBN T52.716: standard or NBN
EN590: low sulphur
CH : SN 181160-2: extra-light fuel oil
and low sulphur eco fuel oil
DE: DIN 51603-1: standard and low
sulphur.
The design and function of the burners
meet standard EN 267.
Assembly, commissioning and
maintenance must be carried out only by
authorised specialists and all applicable
guidelines and regulations must be
observed.
Burner description
VECTRON L 02.120/160/210 DUO
burners are 2-stage, fully automatic,
monoblock type burners. They are
suitable for use with all heat generators
complying with EN 303 or for use by hot
air generators complying with DIN 4794
or DIN 30697 within their respective
performance range. Any other type of
application requires the approval of
ELCO.
Scope of delivery
The burner packaging also contains:
- 1 connection flange with insulation
- 1 bag containing mounting parts
- 1 bag containing Technical
Documentation
44
Contents.................................................................. 44
Important information .............................................. 44
Technical data, power graphs................................. 45
Dimensions, burner description .............................. 46
Operating mode, safety function ............................. 47
Automatic combustion control unit .......................... 48
Allocation chart, connection socket......................... 49
Connection options, oil burner pump ...................... 50
Burner assembly, burner installation position ......... 51
Electrical/oil connection .......................................... 52
Checks before commissioning ................................ 53
Adjustment data, mixing unit check ........................ 53
Air regulation, oil pressure regulation ..................... 54
Adjusting burner output........................................... 55
Maintenance ........................................................... 56
Troubleshooting ...................................................... 57
The following standards should be
observed in order to ensure safe,
environmentally sound and energy-
saving operation:
EN 226
Connection of vaporising oil and forced
draught gas burners to the heat
generator
EN 60335-2
Safety of electrical equipment for
domestic use
Installation location
The burner must not be used in rooms
with aggressive vapours (e.g. hair spray,
perchloroethylene, carbon
tetrachloride), high levels of dust or high
air humidity (e.g. laundry rooms).
If no connection to an air exhaust
system is provided for the air supply,
there must be a supply air inlet
measuring:
DE : up to 50 kW: 150 cm
per additional kW: + 2.0 cm
CH : QF [kW] x 6= ...cm2; but at least
150 cm
Variations may arise as a result of local
regulations.
12/2007 - Art. Nr. 13 023 653A
2
2
2
.
Declaration of conformity
for forced draught oil burners
We, factory certified with Nr. AQF030
F-74106 ANNEMASSE Cedex
declare under our sole responsibility
that the products
VECTRON L 02.120 DUO
VECTRON L 02.160 DUO
VECTRON L 02.210 DUO
conform to the following standards
EN 50165
EN 55014
EN 60335
EN 60555-2
EN 60555-3
EN 267
Belgian royal decree dated 08/01/2004
These products bear the CE mark in
accordance with the stipulations of the
following European Directives
89 / 392 /EEC Machinery Directive
89 / 336 /EEC EMC Directive
73 / 23 /EEC Low Voltage
Directive
92 / 42 /EEC Efficiency
Directive
Annemasse, 6th June 2005
J.HAEP
The warranty does not cover damage
arising from:
- inappropriate use.
- incorrect assembly or repair by the
customer or any third party, including
the fitting of non-original parts.
Final delivery and instructions for
use
The firing system manufacturer must
supply the operator of the system with
operating and maintenance instructions
on or before final delivery. These
instructions should be displayed in a
prominent location at the point of
installation of the heat generator, and
should include the address and
telephone number of the nearest
customer service centre.
Notes for the operator
The system should be inspected by a
specialist at least once a year. It is
advisable to take out a maintenance
contract to guarantee regular servicing.
