Important notes
VECTRON L 04.350/480 DUO burners
are designed to burn EL mineral
heating oil conforming to DIN 51 603.
The burners must be assembled and
started up with care by a specialist, in
accordance with the relevant
instructions and guide lines.
Requirements
For safe, environmentally friendly and
energy-saving operation, the following
standards must be respected:
EN 303
Heating boilers
DIN 4705
Calculation of flue dimensions
EN 267
Atomizing oil burners
DIN 4755
Fuel-oil fired installations
EN 226
Connection of atomizing oil burners
EN 60335-2
Safety of electrical appliances for
domestic use
Repair works on switches, limiters,
control and safety units and other
safety installations should be carried
out only by the respective
manufacturers of each device or their
representatives. Replacement of
original spare parts must be entrusted
to specialists. In accordance with the
operator must have received training in
the functioning of the burner.
14
Clarification of our conditions of
guarantee
This guarantee does not cover damage
resulting from:
inappropriate or improper use
–
incorrect assembly or repair by the
–
purchaser or a third party, including
the use of spare parts from outside
manufacturers
operating the installation under
–
excessive pressure.
Necessary conditions for efficient
operation are:
regular boiler maintenance
–
operation of the installation within the
–
limits of factory performance data
use of suitable fuel
–
Note for users
The burner will continue to function
safely and efficiently provided it
receives regular servicing, at least once
a year. It is strongly recommended to
take out a service contract to guarantee
regular servicing.
08/2005 - Art. Nr. 13 018 076A
Product description
VECTRON L 04.350/480 DUO
two-stage fuel-oil burners are designed
for use with boiler of which furnace is or
is not pressurized.
The burners are equipped with two
nozzles and are pre-set in the factory.
Construction of the burner
The burner consists of a die-cast light
alloy housing. The fan turbine is at right
angles to the axis of the burner head
and is separated by a die-cast carrier
plate. Air flow control is effected by an
electrically powered air flap servomotor.
An air shutter prevents cold air from
being drawn in and flowing through the
boiler. This reduces boiler cooling to a
minimum. The burner plate carries all
the burner equipment, i.e.:
electric motor
–
fan turbine
–
oil pump
–
ignition transformer
–
air flap servomotor
–
electrical connections
–
burner head
–
control unit and flame detector
–
After removal, the burner equipment
plate can be attached to the housing in
servicing position.
