Pepperl+Fuchs IDENTControl IC-KP-B12-V45 Handbuch Seite 124

IC-KP-B12-V45
Anhang B
Ausgangs-Instanz 104d - 32 Bytes
Bytes
Ausgangs-Instanz 105d - 48 Bytes
Bytes
Ausgangs-Instanz 106d - 128 Byte
Bytes
Ausgangs-Instanz 107d - 240 Byte
Bytes
120 - 179
180 - 239
Ausgangs-Instanz 108d - 40 Bytes
Bytes
124
Klasse, Instanz, Attribut
0 - 7 64h, 01d, 01h
8 - 15 64h, 02d, 01h
16 - 23 64h, 03d, 01h
24 - 31 64h, 04d, 01h
Klasse, Instanz, Attribut
0 - 11 64h, 01d, 02h
12 - 23 64h, 02d, 02h
24 - 35 64h, 03d, 02h
36 - 47 64h, 04d, 02h
Klasse, Instanz, Attribut
0 - 31 64h, 01d, 03h
32 - 63 64h, 02d, 03h
64 - 95 64h, 03d, 03h
96 - 127 64h, 04d, 03h
Klasse, Instanz, Attribut
0 - 59 64h, 01d, 04h
60 - 119 64h, 02d, 04h
64h, 03d, 04h
64h, 04d, 04h
Klasse, Instanz, Attribut
0 - 7 64h, 01d, 01h
8 - 15 64h, 02d, 01h
16 - 23 64h, 03d, 01h
24 - 31 64h, 04d, 01h
32 - 39 64h, 05d, 01h
Beschreibung
Channel 1 [8]
Channel 2 [8]
Channel 3 [8]
Channel 4 [8]
Beschreibung
Channel 1 [12]
Channel 2 [12]
Channel 3 [12]
Channel 4 [12]
Beschreibung
Channel 1 [32]
Channel 2 [32]
Channel 3 [32]
Channel 4 [32]
Beschreibung
Channel 1 [60]
Channel 2 [60]
Channel 3 [60]
Channel 4 [60]
Beschreibung
Channel 1 [8]
Channel 2 [8]
Channel 3 [8]
Channel 4 [8]
IDENT Control
