IMPORTANT INFORMATION
Warning : LOOK products are designed and
!
optimized for cyclists weighing no more than
100 Kg (220.5 lbs). Road bikes are designed
for use only on paved roads and in situations
where the tires do not lose contact with the ground.
Jumping is forbidden.
Counterfeit warning: The use of counterfeit
!
products is extremely dangerous and may
cause you and/or others to fall, resulting in
serious injury or even death.
Your 796 Monoblade has been developed and
designed to LOOK specifications to offer optimum
performance and the best possible power transfer
through a race-tuned frame geometry.
This is in part due to the integration of components
specifically-designed for the frame. The result
is a more coherent overall system, improved
performance and full integration of all cables and
hoses. The 796 Monoblade features a completely
new, 100% carbon stem and basebar combo. The
headset includes new bearings and dedicated
spacers that offer harmonious internal cable and
hose routing in combination with the new stem.
For more information, please refer to our website
www.lookcycle.com > WARRANTY POLICY >
COUNTERFEIT
For more details on IMPORTANT INFORMATION
to be aware of, please refer to our website
www.lookcycle.com, WARRANTY POLICY >
IMPORTANT INFORMATION.
If you cannot access our website, your local
retailer can provide you with a printed copy
of our warranty policies.
INTRODUCTION
Here are the key components of your new 796
Monoblade:
- 100% carbon bar/stem combo
- 100% carbon seatpost
- Stainless steel upper bearing 32.8 internal / 41.8
external, Height 6.0, Slopes 45/45
- Stainless steel lower bearing 30.15 internal / 41.0
external, Height 6.5, Slopes 45/45
- X12 thru axles. Front: 100 mm M12 P1,5 total
length 115 mm. Rear: 142 mm M12 P1,5, total length
160 mm
- T47 bottom bracket, 85,5 mm width
- Chainstay thickness for disc brake caliper mount:
25 mm
- Max. tire width: 32 mm
PRE-ASSEMBLY CHECK
- Your frame is delivered with:
- Fork and headset
- A pouch including necessary accessories.
- Dedicated stem, basebar, seatpost, thru axles
and extension bars.
