ICE11-8IOL-G60L-V1D
IIoT-Funktionalität
Name
iolink_text
aux_mode
aux_text
cq_mode
iq_mode
port_status
ds_fault
ds_fault_text
device
diag
Tabelle 10.25
1. always on
2. can be controlled by cyclic data
DIAG Object
Name
error
source
eventcode
eventqualifier
message
Tabelle 10.26
DEVICE Object
Name
device_id
vendor_id
serial
baudrate
cycle_time
input_len
output_len
g. Standard parameters of the IOL-Device
Datentyp Beschreibung
string Textual representation of the current port
mode
number Indicates the configured mode for the Pin
2:
0 = No AUX
1 = AUX output
2 = Digital output
3 = Digital input
string Textual representation of the current aux
mode
number Port mode according to IOL specification
number Pin 2 mode according to IOL specification
number Port status according to IOL specification
number Data storage error number
string Textual data storage error
DEVICE Object IO-Link device parameters.
• Null if no IO-Link communication active
array of DIAG (n) Array of port related events
Datentyp Beschreibung
number Error code
string Source of the current error.
number Event code according to IO-Link specifi-
cation
number Event qualifier according to IO-Link speci-
fication
string Error message
g
Datentyp Beschreibung
number
number
string
string Baudrate (COM1,2,3)
number Cycle time in microseconds
array of numbers (n) IOL input length in bytes
array of numbers (n) IOL output length in bytes
1
2
Beispiel
"device"
"master"
"Supply Voltage fault"
Beispiel
Beispiel
"Digital Input"
"AUX Output"
