ICE11-8IOL-G60L-V1D
IIoT-Funktionalität
CHANNEL Object
Name
name
type
type_text
config
config_text
inputState
outputState
forced
simulated
actuatorDiag
sensorDiag
maxOutputCurrent _mA number
current_mA
voltage_mV
Tabelle 10.24
1. producing data
2. = Pin 1
3. if current measurement is available
4. if voltage measurement is available
PORT Object
Name
port_type
iolink_mode
168
Datentyp Beschreibung
string Name of channel
number Hardware channel type as number:
0 = DIO
1 = Input
2 = Output
3 = Input/Output
4 = IO-Link
5 = IOL AUX
6 = IOL AUX with DO
7 = IOL AUX with DO. Can be deactivated.
8 = Channel not available
string Textual representation of the channel type
number Current configuration of the channel:
0 = DIO
1 = Input
2 = Output
3 = IO-Link
4 = Deactivated
5 = IOL AUX
string Textual representation of the current config
boolean
Input data
boolean Output data bit to the physical output pin
boolean True, if the output pin of this channel is
forced
boolean True, if the input value to the PLC of this
channel is simulated
boolean True, if the output is in short circuit / overload
condition
boolean
True, if the sensor supply
overload condition
Maximum output current of the output in mA
number
Measured current of the output in mA
number
Measured voltage of this output in mV
Datentyp Beschreibung
string Textual representation of the IO-Link port
type
number Current port mode:
0 = Inactive
1 = Digital output
2= Digital input
3 = SIO
4 = IO-Link
1
bit to the PLC
2
is in short circuit /
Beispiel
3
4
Beispiel
