13. Slide the braided sleeving over the rope
clamp.
14. Use the overhanging tensioning rope ends
to tie a knot before and after the rope clamp
and wind the tensioning rope ends into
loops. These should not be longer than 30
cm and are fixed to the tensioned rope
centrally over the rope clamp on the right
and left using cable ties.
CAUTION:
The unit is now tensioned!
The running of the tensioning rope must be
checked.
Note:
The tensioning rope should not get stuck
between the projection profile (1) and the
projection profile cover (2) (detail A).
