Remove the double-sided adhesive tape's protective film and press the fabric onto it. Slight
corrections are still possible, as full adhesion is only achieved later.
Connect the test run cable and press the retract button until the fabric is wound up so far on
the Optinut roller tube shaft and the projection profile is still approx. 30 cm in front of the
cassette. As you do this, make sure that the fabric is wound up evenly and centrally.
Replace the bottom of the cassette and fasten the straps.
Close the cassette and secure it to the headplates using M4 hexagon socket head screws.
Reinsert the cassette & reattach the side channels.
Chapter 3.5 "Inserting the tensioning rope after changing the fabric" describes how to
tighten the system again.
Perform a test run as described in the assembly instructions.
Align the system according to the assembly instructions.
Re-fit the bracket covers to the brackets.
Close the projection profile again.
Reprogram the end position, if required.
