Functional check
Equipment
EMERGENCY-STOP
mushroom switch
Positions switch
Lathe chuck protection
Positions switch
Protective cover of the
headstock
Positions switch
Spindle brake
Date:
1.11

Personal protective equipment

For certain work personal protective equipment is required.
Protect your face and your eyes: Wear a safety helmet with facial protection when performing
work where your face and eyes are exposed to hazards.
Wear protective gloves when handling pieces with sharp edges.
Wear safety shoes when you assemble, disassemble or transport heavy components.
Use ear protection if the noise level (emission) in the workplace exceeds 80 dB (A).
Before starting work make sure that the required personal protective equipment is available at
the work place.
CAUTION!
Dirty or contaminated personnel protective equipment can cause illness.
It must be cleaned after each use and at least once a week.
1.12

Safety during operation

We provide information about the specific dangers when working with and on the lathe in the
descriptions for these types of work.
WARNING!
Before activating the lathe ensure that this will neither endanger other persons nor
cause damage to equipment.
Avoid any unsafe work methods:
Avoid any unsafe work methods:
Make sure that your work does not endanger anyone.

Clamp the workpiece tightly before activating the lathe.

Observe the maximum lathe chuck opening.

Wear safety goggles.

Do not remove the turning chips by hand. Use a chip hook and / or a hand brush to remove

turning chips.
Version 1.0.2 - 2022-05-02
Check
After activating the emergency stop mushroom button, the control voltage on
the lathe will shut off. The spindle continues to rotate for a while, depending on
the mass moment of inertia of the spindle and workpiece.
The spindle drive of the lathe must only be switch on if the lathe chuck
protection is closed.
The spindle drive of the lathe must only be switch on if the protective cover of
the headstock is closed.
The lathe must be switched off if the mechanical spindle brake is activated.
Checked by (signature):
Translation of original operating manual
TH4210 | TH4210D | TH4215D
OK
EN
105
