General
3.2

Survey and construction

Suspension eye
Backdrop for
cones
respectively rings
Circulation
Claw holder
Claw II
3.3

Technical data

The exact technical data (carrying capacity / working load limit (WLL), dead weight, etc.) are listed on the type plate.
54000041
Guide tube
Hinged cotter pin
Claw III
Movable Carriage for
Change machine
11 / 33
Center of gravity
compensation
Hiding bolt for
to adjust the stop
for the slide
Guide shaft
Hiding bolt for
adjustment of the
Gripping range
