probst SVZ-UNI-VARIO Betriebsanleitung Seite 57

Adjustments
Fig. 2
Variant: Application for:
Bracket II manholes
*
= (NW) Nominal width of gripping goods
** = Tolerance ± 10 mm (± 7/16")
ATTENTION: when gripping manhole basers
Fig. 1A
54000041
Nominal width
Marking
Pos.1
*
NW (Inner-Ø) mm
1000, 1050, 1200, 1250, 1350, 1500
When gripping manhole bottom parts with
bracket II, bracket III must be moved first into
the "stand-by position"!
Bracket holder
Bracket II
Stand-by position
Bracket III
16 / 33
**
Parkposition „P"
GB
