English - IKAR HRA Prüfbuch Und Gebrauchsanleitung

1. The IKAR Fall Arrest Block HRA with recovery mechanism in accordance with EN 360:2002
/ EN 1496:2007 B und 2359.14-2014 is an automatic fall arrest system, part of a fall protec-
tion PPE with integrated fall restraint functions to serve as a fall arrest and recovery lifting
device.In conjunction with a safety harness (EN 361 :2002 / EN 1497:2007, ANSI/ASSE
2359.1-2007), the HRA device provides safety for persons carrying out work with a risk of
falling (e.g.when moving in containers, vertical shafts, sewer systems). With the recovery
mechanism, the lifeline is wound up to litt the casualty in an emergency. The HRA device
may only be used for the intended purpose.
2. The instructions for use are to be fully read and understood before use. Nonobservance of
the instructions for use will put lives at risk (Fig. 2). In case of fall, prolonged suspension of
a person for more than 15 minutes must be avoided (risk of shock).
3. The recovery mechanism has only been approved for recovery purposes, not for iving and
lowering loads.
4. Only safety harnesses in accordance with EN 361, EN 361 / EN 1497, ANSI/ASSE
2359.1-2007 are permitted for use with the fall arrest block with recovery mechanism (other
harnesses are not permitted) (Fig. 3).
5. One device can only protect one person at a time, but can be used successively by several
persons.
6. A rescue plan covering any rescue case that might occur du ring work must exist.
7. During the rescue operation, there must always be direct or indirect visual or communica-
tive contact with the person to be rescued.
8. A suffi ciently strong, suitable fastening point corresponding to the national regulations with
a min. load-bearing capacity of 9 kN (North America 22.2 kN) must be chosen for the hand
chain device. The fastening is done with snap hooks according to EN 362:2004 / ANSI/
ASSE 2359.12-2009 (mountaineering karabnerhooks) or sling according to EN 795, whe-
reby the sling is pulled through the bracket of the handdevice and closed with a secured
snap hook. In case of devices with swivel eye hanging, the snap hook is connected to the
anchorage point and rotatable swivel eye.
9. The HRA device should be in a perpendicular position above the head of the person to be
rescued in order to prevent swinging (Fig. 6). The suspension of the device must allow for
compensating deviations in rope/webbing length. When the device has been attached to
the anchorage point, attach the end of the connecting device (karabiner type connector) to
the ring attachment point of the safety harness. lf the karabiner hooks are not self-locking,
they must be screwed tight with a sleeve nut.
10. The HRA fall arrest block with winding handle can only be used as part of a fall arrest
system in conjunction with the holders and support brackets of the IKAR GmbH . The inst-
ructions for use and their components must be observed.
11. Before every use, check the readability of the product label.
12. A visual inspection and functional test of the HSA fall arrest block must be performed
before every use (Fig. 7). To do so, attach the fall arrest block to a suitable anchor point:
Pull the rope, the ratchets must lock audibly and the device must be locking. Firmly hold
the rope and allow it to retract into the fall arrest block in a controlle manner. lf the rope is
released, it may cause injuries and damage by its quick and uncontrolled retraction into the
housing. Check the karabiner hook for proper functioning (self-closing, lockable). Check the
retractable connecting device for proper condition. A HRA fall arrest block with a damaged
connecting element or device (Fig. 7a + 8), e.g. ropes with a kink or broken/torn strand,
must not be used.
13. A fall arrest block must be withdrawn from use if damaged, loaded by fall or if its safe con-
dition is doubtful. lt may only be used further if tested and released in writing by an expert
from or trained by the manufacturer.
14. Fall arrest blocks must not be used for securing persons working above bulk goods or
similar substances where people can sink in (Fig. 9).

ENGLISH

lnstructions for use
12
2
3
4
5
6
7
7a
8
9
