SPARE PARTS LIST FOS-500
REF NR DESCRIPTION
001 PLASTIC PLATE
002 BASE PLATE
005 KNOB
006 LEVER FOR FIXING RING
007 NUT
008 COLLET 1/4"
009 COLLET 1/8"
012 BEARING
016 LOCKING PIN
019 ROTOR
020 BEARING (608 Z)
021 RUBBER BEARING HOLDER
025 STATOR
028 CARBON BRUSH SET
037 SWITCH
044 KNOB FOR HANDLE
045 HANDLE
046 WRENCH
66
UK
FERM NR
408700
OMNISAW
408701
408702
THE NUMBERS IN THE FOLLOWING TEXT COR-
408703 RESPOND WITH THE PICTURES AT PAGE 2
408704
TECHNICAL SPECIFICATIONS
408705
408706
Voltage
Frequency
408707
Power input
408708
Speed, no load
408709
Nett weight
Lpa (sound pressure)
800608
Lwa (sound power level)
408710
Vibration value
408711
408712
DESCRIPTION
Fig.A
408713
1. Base plate and depth guide
408714
2. Collet nut
408715
3. Spindle lock button
4. Exhaust air vents
408716
5. Removable auxiliary handle
6. On/off slide switch
7. Intake air vents
8. Power supply cable
9. Depth guide bracket
10. Depth guide locking knob
11. Locking knob of depth guide bracket
12. Bit
13. Protection guide cap (not shown)
PACKAGE CONTENTS
1 Omnisaw
1 1/4" collet
1 1/4" Window/Door Bit (ZBWD8) for Plaster cutting
1/4"
1 1/8" Guidepoint Bit (GP10) for Drywall cutting 1/8"
1 1/8" Outlet Bit (ZB10) for Plaster cutting 1/8"
2 1/8" Sabrecut Bit (ZBSC5) for Wood/Plastic cutting
1/8"
1 1/8" Tilecut Bit (RZ125) for Ceramic cutting 1/8"
1 Wrench
1 Protection guide cap
1 Carrying case
Check the machine, loose parts and accessories for
transport damage.
Ferm Ferm

SAFETY INSTRUCTIONS

English
The following symbols are used in these instructions for
use:
instructions in this manual.
Carefully read this manual before using the machine.
| 230 V~
Make sure that you know how the machine functions and
| 50 Hz
how to operate it. Maintain the machine in accordance
| 500 W
with the instructions to make sure it functions properly.
| 30000/min
Keep this manual and the enclosed documentation with
| 1.51 kg
the machine.
| 83.9 dB(A)
| 96.9 dB(A)
When using electric machines always observe the
| 4.6 m/s 2
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
BEFORE USING THE OMNISAW
•
•
•
•
•
•
•
•
•
USING THE MACHINE
•
•
•
•
•
Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance of the
Denotes risk of electric shock.
Check the voltage of the motor and the motor over-
load (if any) correspond:
Do the voltage of the engine and the engine safe-
guard, if any, correspond to the mains voltage
(appliances for a mains voltage of 230 V).
Are the mains lead and the mains plug in a good condi-
tion: solid, without any loose ends or damage.
Remove adjusting keys or wrenches before turning
the tool on.
Always wear eye protection when using the tool.
Maintain the tool with care.
Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the tools operation. If damaged, have the tool
serviced before using.
Use only accessories that are recommended by the
manufacturer for your model.
Compare the maximum number of revolutions allo-
wed of the accessories with the number of revolu-
tions of the machine.
Make sure that the spring chuck diameter is the same
as the axle diameter of the accessory.
The flutes of the bits (cutting edges and top) are very
sharp. Therefore, handle with caution.
Use clamps or a vice to hold the work.
Do not use the tool if the switch does not turn it
"ON" or "OFF".
Always hold the tool with two hands while starting.
Hold the tool by the insulated gripping surfaces when
performing an operation where the bit may contact
hidden wiring. If cutting into existing walls or other
blind areas is unavoidable, disconnect all fuses or cir-
cuit breakers to the worksite.
Always keep the cord away from the moving parts of
the machine.
