18 VOLT CORDLESS ELECTRIC SAW
TECHNICAL DATA
Voltage
| 18 V -
Charger voltage
| 230 V ~
Charger frequency
| 50 Hz
Battery output
| 1.3 Ah
Charging time
| 1 hour
Revolutions, idling
| 0 - 2100/min
Cutting length
| 19 mm
Weight (incl. battery)
| 1.9 kg
Lpa (sound pressure level)
| 84.4 dB(A)
Lwa (operating sound level)
| 97.4 dB(A)
Vibration level
| 3.1 m/s
2
PACKAGE CONTENTS
The package contains:
1 Cordless reciprocating saw
1 Battery, 18 V, 1.3 Ah
1 Battery Charger
1 Saw blade for wood
1 Saw blade for metal
1 User manual
1 Guarantee card
1 Safety instructions
Please examine the saw, individual parts and accessories
for transport damage.
2
SAFETY INSTRUCTIONS
The following pictograms appear throughout these
operating instructions:
Indicates danger of injury, risk to life and possible
damage to the appliance if these instructions are
not followed.
Indicates the presence of electrical current.
Read through these operating instructions carefully
before using the appliance. Become familiar with the
functions and method of operation. To ensure proper
operation, always maintain the appliance according to
the instructions. The operating instructions and
associated documents should always be kept close to the
appliance.
When using power tools, you must observe the
follwing basic safety precautions in order to ensure
protection from electric shocks, injury and fire.
Read and follow all the instructions before using this
power tool. Look after the notes on safety.
•
Remove the battery block. When the power tool is
not being used, prior to maintenance and when
changing tools such as the clamping chuck, and drill.
•
The tool is suitable for use as a screwdriver and drill.
Any other application is specifically excluded.
IMPORTANT SAFETY NOTES ON CHARGER
AND BATTERY BLOCK
If you come into contact with acid from the battery
block, rinse it off with water immediately. If acid gets
into your eyes, rinse out your eyes at once with water
and contact a doctor immediately!
1. Read and note the operating instructions and safety
notes for the charger and battery block before use!
2. NB! Only use the charger and battery block that
were supplied by the manufacturer - otherwise you
will risk an accident.
3. Protect the charger, battery block and power tool
from moisture, e.g. rain or snow.
4. Always check that all cables are connected correctly
before using the charger.
5. If you discover that a cable is damaged, you should
not use the charger again. Have the damaged cable
replaced immediately.
6. When the charger is not in use, the mains plug should
be removed from the power socket. Do not pull out
the plug by grasping the cable.
7. If the charger has been dropped or has otherwise
been exposed to high mechanical stresses, you
should have it checked for damage by an authorised
dealer before using it again. Damaged parts should be
repaired.
8. Exercise caution when handling the battery block
and do not drop it or expose it to impacts.
9. Never attempt to repair the charger or battery block
yourself. Repairs must always be carried out by an
authorised dealer - otherwise you risk an accident.
SPARE PARTS DRAWING
SPARE PARTS LIST FCR-18KN
REF. NR.
1
2
3
4
5
-
Ferm
Ferm
3
4
5
DISCRIPTION
BATTERY 18 V
SWITCH
MOTOR 18 V
TRANSMISSION
SAWBLADE HOLDER
1-STD BATTERY CHARGER
1
2
FERM NR.
818883
406654
408752
408753
408730/408731
406655
79
