Inhaltsverzeichnis - MSA PrimaX IR Gebrauchsanleitung

Vorschau ausblenden Andere Handbücher für PrimaX IR:
Inhaltsverzeichnis

Werbung

Inhalt
1
Sicherheitsvorschriften . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1
Bestimmungsgemäße Verwendung . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2
Haftungsausschluss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3
1.4
MSA Garantie für stationäre Geräte . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2
Beschreibung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1
Benutzeroberfläche. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2
Paketinhalt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3.1
Mechanische Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3.2
Elektrische Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Kabelanschlüsse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Externe Steuersysteme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4
Start und Kalibrierung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1
Inbetriebnahme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Kalibrierungen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2
PrimaX IR-Kalibrierung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Bump-Test-Verfahren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Kalibrierung mit dem Kalibrieradapter. . . . . . . . . . . . . . . . . . . . . . . . 22
Kalibrierung mit HART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.3
Kalibriersets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5
Wartung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1
Allgemeines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.2
Fehlerbehebung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.3
HART-Informationen für die Fehlerbehebung . . . . . . . . . . . . . . . . . . 30
5.4
Reinigung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.5
Reinigen der Umgebungsschutzvorrichtung . . . . . . . . . . . . . . . . . . . 33
5.6
Reinigungsvorgang für den Kalibrieradapter . . . . . . . . . . . . . . . . . . 33
PrimaX® IR
DE
3
