Keep the splitter clean at all times. Use regularly sold hydraulic oil (HLP 46 #
42004 or any other product of identical viscosity) for changing the hydraulic oil.
The oil level in the splitter must always be between min. and max marks. Make
sure the splitter is always in an erected position.
Hydraulic oil change: Put a suitable container (pic. 8 Art. 11) under the hydraulic
oil drain screw and screw the drain screw out.
Caution! Old oil must be disposed in accordance with valid
regulations.
To that end, please get in touch with old oil disposal centres.
Disposing oil in any other manner strictly prohibited. Such acting would be
subject to prosecution and considerable punishment.
Now screw up the drain screw again. Caution! No impurities can get in any
circumstances in the hydraulic oil tank. Now fill in the hydraulic oil tank and check whether there is a
correct hydraulic oil level in the tank using a gauge. Attention: Always fill the oil only when the splitting
post is inserted!
Only original spare parts can be used when changing or replacing any construction parts. Regularly check
hydraulic hoses and hose joints for tightness.
Inspection and Maintenance Plan
Time interval:
Before each use
App. after 4 hours of operation Check hydraulic hoses and joints for tightness; tighten
App. after 500 hours of

operation

Service
Do you have any technical questions? A claim? Do you need spare parts or the Operating
Instructions?
You will be helped quickly and without needless bureaucracy at our webpage www.guede.com in the
Service part. Please help us be able to assist you. To be able to identify your appliance when claimed, we
need to know its serial No., order No. and year of production. All these details can be found on the type
label. Enter the details below for future reference.
Serial No.:
Order No.:
Year of production:
Tel.: +49 (0) 79 04 / 700-360
Fax: +49 (0) 79 04 / 700-51999
E-Mail: support@ts.guede.com
Description
Lubricate the splitting post / check the engine oil level
them if necessary.
Change the hydraulic oil. Clean the oil filter in the tank,
replace if necessary.
Any other
details
