Technical Data - SATA paint set 10 Betriebsanleitung

Operating Instructions SATA FDG
EN
[10‑25] Spraying air ball valve
[10‑26] Spraying air connection
[10‑27] Material supply connection
[10‑28] Material supply ball valve
Hand agitator
[11‑7] Hand crank for agitator
Motor driven agitator
[12‑1] Electric motor for agitator
Compressed air agitator without gear drive
[13‑1] Air micrometer (air flow control knob)
[13‑2] Silencer (concealed)
[13‑3] Air Motor
[13‑4] Pneumatic motor air connection
Compressed air agitator with gear drive
[14‑1] Air micrometer (air flow control knob)
[14‑2] Pneumatic motor with gear
[14‑3] Sound absorber
[14‑4] Pneumatic motor air connection

8. Technical Data

8.1. Paint pressure tank
Description
Max. operating pres-
sure
Max. permissible op-
erating temperature
Contents
Fluid / fluid group
Clear inner diameter
Clear inner height
Weight without insert
pot and agitator
170
paint set 10
3 bar 43 psi
-10 °C – +50 °C
10 2.6 gal
litres
2
217 8.5
mm inch
268 10.5
mm inch
8 kg 17.6
lbs
FDG-24
6 bar 87 psi
+14 °F – +122 °C
24 6,3 gal
litres
2
297 11.7
mm inch
396 15.6
mm inch
24 kg 53 lbs
FDG-48
4 bar 58 psi
48 12.7
litres gal
2
362 14.2
mm inch
468 18.4
mm inch
31 kg 68.3
lbs
