Operating Instructions SATA FDG
Description
Optional material
outlet at bottom of
tank
8.2. Motor driven agitator
Description
Protection category
Voltage
Power
Motor speed
Weight
8.3. Pneumatic agitator with / without gear
Description
Protection category
Operating pressure
Air consumption
Power
Speed without gear
Speed with gear 1:25
Weight without gear
Weight with gear

9. First Use

The material pressure tank is supplied fully assembled and ready for op-
eration.
After unpacking, check:
■ Material pressure tank damaged.
■ Scope of supply complete (see chapter 6)
paint set 10
–
2,0 – 6,0 bar
FDG-24
G1
II 2G Ex h IIB T4 Gb.
230 / 400 V 50 Hz
ca. 100 U / min.
6,3 kg
II 2G Ex h IIB T4 Gb.
29 psi – 87 psi
100 – 600 Nl / min
0,05 – 0,6 kW.
50 – 120 U / min
1 kg
1,8 kg
EN
FDG-48
–
0,12 kW
14 lbs
on request
2.2 lbs
4 lbs
