Operating Instructions SATA spray master RP
EN

6. Technical Design

6.1. Spray gun

Quick coupling connection
[1-1]
for SM pressurized cup with
check valve
Safety and bleeder valve
[1-2]
Air hose for pressure cup
[1-3]
Material flow control with
[1-4]
counter nut
[1-5] Air micrometer
[1-6] Locking screw
Fully variable round/flat fan
[1-7]
control

7. Technical Data

Description
Recommended spray gun inlet
pressure
Max. spray gun inlet pressure
Max. air working pressure
Max. cup pressure
Cup pressure variable from
Recommended spraying distance
Air consumption
Max. temperature of the material
Weight (without material)
aluminium flow cup 750 ml

8. Operation

Warning!
Risk of injury from bursting compressed air hose
If an unsuitable compressed air hose is use, it can be damaged by too
much pressure and explode.
→ Only use solvent-resistant, antistatic and technically flawless hose
for compressed air with permanent pressure resistance of min. 10 bar,
bleeder resistance of < 1 MOhm and min. inner diameter of 9 mm
(# 9902).
128
Pressure gauge for cup
[1-8]
pressure
[1-9] Air connection
[1-10] Regulation knob
[1-11] Safety valve for regulator
fitting
[1-12] Trigger
[1-13] Nozzle set
[1-14] Pressurised cup
[1-15] Screw-on lid
150 - 230 Nl/min at 1 - 2 bar
RP
1.0 bar - 2.0 bar
10.0 bar
3.0 bar
1.7 bar
0 - 1.7 bar
17 cm - 21 cm
50 °C
1300 g
