Scope Of Delivery; Technical Design - SATA paint set 10 Betriebsanleitung

Operating Instructions SATA FDG
EN
Second gun connection [1-4] / [7-6]
For connecting a second gun.

6. Scope of Delivery

■ Material pressure tank, depending on the variant
■ Key for refill opening

7. Technical Design

7.1. SATA paint set 10
Material pressure tank SATA paint set 10 [1]
[1‑1] SATA paint set 10 with
manual agitator
SATA paint set 10 with
[1‑2]
pneumatic agitator with
gear
SATA paint set 10 with
[1‑3]
single pressure reducer
[1‑4] SATA paint set 10 with
double pressure reducer
and second gun connection
Single pressure reducer
[2‑61] Material supply ball valve
[2‑62] Material supply connection
[2‑63] Safety valve
[2‑64] Ventilation valve
[2‑65] Material pressure controller
[2‑66] Spraying air connection
Double pressure reducer
[3‑61] Material supply ball valve
[3‑62] Material supply connection
[3‑63] Safety valve
[3‑64] Ventilation valve
[3‑65] Material pressure controller
[3‑66] Spraying pressure
controller
Second gun connection
[4‑25] Material supply ball valve
[4‑26] Material supply connection
[4‑27] Spraying air ball valve
168
[1‑5] Container lid
[1‑6] Material supply connection
Clamp
[1‑7]
Pressure tank
[1‑8]
Ventilation valve
[1‑9]
[1‑10] Toggle screw
[1‑11] Double pressure reducer
[1‑12] Handle
[2‑67] Spraying air ball valve
[2‑68] Single pressure reducer
[2‑69] Compressed air supply ball
valve
[2‑70] Compressed air supply
connection
[3‑67] Double pressure reducer
[3‑68] Spraying air connection
[3‑69] Compressed air supply ball
valve
[3‑70] Compressed air supply
connection
[4‑28] Spraying air connection
