Setting
8 – 3 Programming the system operation
Eight programs can be memorized and recalled according to treatment procedures�
1 Press to select a program number�
2 Press to select the rotation direction:
Forward rotation (clockwise)
Reverse rotation (counterclockwise)
* Beep sounds constantly when reverse rotation is
selected�
3 Press to select gear ratio for handpiece used�
4 Press to set the maximum rotation speed�
* When rotating: displays actual speed
* When stopped: displays maximum speed set�
* Beep sounds when upper or lower limit is reached�
6 2
7
5 Press
Reduction contra with rotation speed of 100min
less only)
* Stops once at 50N•cm� If setting to greater than
55N•cm, press
* Beep sounds when upper or lower limit is reached�
* No display when the gear ratio is other than 20:1�
6 Press to select coolant solution flow level�
7 Press to select light brightness�
8 Press to memorize setting (Memorizing is
complete when long beep sounds)�
38
4 5
3 8 1
to set torque upper limit (20:1
again�
or
-1
