6) Place a layer of carbon fibre cloth strap anteriorly and posteriorly
from the shuttle lock to the circular carbon fibre cloth strap (see
fig. 8).
7) Pull a tube sock over the plaster positive.
8) Loop a piece of string around the lamination adapter in the groove
and tie tightly (##03119).
9) Cut a piece of carbon UD hose (1.5 times the length of the plaster
positive).
10) Pull the carbon UD hose over the plaster positive up to the socket
edge. Tie the upper section of the carbon UD hose and fold the
remaining length over the plaster positive.
11) Loop a piece of string around the lamination adapter in the groove
and tie tightly (see fig. 9).
12) Pull a tube sock over the plaster positive.
13) Cut a piece of carbon fibre woven hose (1.3 times the length of
the plaster positive).
14) Pull the carbon fibre woven hose over the plaster positive to the
socket edge. Tie the upper section of the carbon fibre woven
hose and fold the remaining length over the plaster positive (see
fig. 10).
15) Cut a piece of Perlon stockinette (twice the length of the plaster
positive).
16) Pull the Perlon stockinette over the plaster positive up to the sock­
et edge. Tie the upper section of the Perlon stockinette and fold
the remaining length over the plaster positive.
17) Soak the longer PVA bag and pull it over the plaster positive.
18) Perform the casting process with Orthocryl.
19) Finish the prosthetic socket (see page 16).
5.1.4 Laminating a transfemoral socket
> Required tools and materials:
99B81=100X26X5 and 99B81=130X26X5 PVA Bag, 623T3=12 or
623T3=15 Perlon Stockinette, 81A1=12 or 81A1=15 Tube Sock,
616B1=50x* Carbon Fibre Cloth Strap, 616G2 Carbon UD Hose,
616G15 Carbon Fibre Woven Hose, 617H119 Orthocryl Lamina­
tion Resin 80:20 PRO, string
1) Prepare for fabrication of the prosthetic socket (see page 14).
2) Soak the shorter PVA bag and pull it over the plaster positive.
3) Pull a layer of Perlon stockinette over the plaster positive.
4) Place a layer of carbon fibre cloth strap circularly 3 cm below the
perineum.
5) Place a layer of carbon fibre cloth strap medially and laterally as
well as anteriorly and posteriorly from the shuttle lock up to the
circular carbon fibre cloth strap.
6) Place a layer of carbon fibre cloth strap circularly 3 cm below the
perineum.
7) Cut two pieces of carbon fibre cloth strap (length approx. 20 cm).
8) Form the carbon fibre cloth straps into Vs by folding them in the
middle and position them in the area of the tuberosity support.
9) Pull a tube sock over the plaster positive.
10) Loop a piece of string around the lamination adapter in the groove
and tie tightly.
11) Cut a piece of carbon UD hose (1.5 times the length of the plaster
positive).
12) Pull the carbon UD hose over the plaster positive up to the socket
edge. Tie the upper section of the carbon UD hose and fold the
remaining length over the plaster positive.
13) Loop a piece of string around the lamination adapter in the groove
and tie tightly.
14) Pull a tube sock over the plaster positive.
15) Cut a piece of carbon fibre woven hose (1.3 times the length of
the plaster positive).
