4.7) MESSAGES - ADVANCED PROGRAMMING WITH PARTICULAR CONNECTIONS
↓ ↑
VOC. EVENT 1
GROUP AL. A B C
↓ ↑
VOC. EVENT 1
24H TECHN. AL.
↓ ↑
VOC. EVENT 1
TEMPERATURE
4.7.1) REPLACING VOCAL EVENT: it is possible to couple a vocal message to a different event to that proposed as per standard:
MAINS FAILURE (5500-5502 control units only): automatic call after a programmable time (SETTINGS) of no electric current to the
control unit - message example: "attention! No current in Rossi house, via Giovanni Pascoli 10 Turin"
PERIODIC MESSAGE: automatic call every so many hours (programmable in SETTINGS menu) confirming the operational status of the
control unit - message example: " regular alarm functioning Rossi house, via Giovanni Pascoli 10 Turin"
TEMPERATURE ALARM: automatic call when the temperature of the control unit rises above 70°C or falls below 5°C - message example:
"attention! Abnormal temperature in Rossi house, via Giovanni Pascoli 10 Turin"
4.7.2) VOCAL EVENT ASSOCIATED TO A SPECIFIC SITUATION - Display
It is possible to make a specific event trigger a call, transmitting the recorded vocal message appropriately for the purpose. The possible events
are:
ALL = alarm
BATT = low battery
OPEN = door open
ARM A/B/C = specific zone armed
To program the function, write the event in the first part of the display, exactly as indicated above in capital letters (example: to arm write ARM
and confirm ↵), now write the "name" given to the device that generates the even in the second part (see EXTRAS) and confirm ↵: for the
control unit write CONTROL PANEL. Note: to program an event generates by a detector, this must be programmed before.
4.7.3) NO EVENT display: confirming there will be no calls of any type to connected numbers.
4.8) EXTRAS: the additional system devices on the control unit are programmed using this menu.
- REMOTE CONTROLS:
- CODES:
- ZONE ALARM A (B,C):
- 24H PANIC:
- 24H ROBBERY:
- 24H TECHNOLOGICAL:
- EXTERNAL KEY:
- WIRED ZONES:
4.8.1) REMOTE CONTROLS
↑
EXTRAS
↵ ↓
CONFIRM
Each control can switch on-
off one or more groups:
choose the group A,B,C by
pressing 1, 2, 3, 4, 5, 6.
LABEL REM. CTRL. 01
_ _ _ _ _ _ _ _ _ _ _ _ _
VOCAL RECORDING
232 . 231 . 230 . 229 . . .
SILENTRON spa – 10139 – Via Sagra S.Michele 25 Torino - ITALIA
↓
↓ ↑
VOC. EVENT 1
TAMPERING AL.
↓ ↑
VOC. EVENT 1
↓
LOW BATTERY
↓ ↑
VOC. EVENT 1
↓
_ _ _ _ _ _ , _ _ _ _ _ _
SUPERV = supervision alarm
ARM = control unit armed
F ALL = door re-closed
portable transmitters for arming/disarming the control unit
groups of 5 numbers for arming/disarming the control unit using the keypad on board and/or other
group of anti-intruder detectors that are armed together - 3 groups available A,B,C
zone always active where the buttons (remote controls, keypads) are programmed to trigger manual alarm
zone always active where the buttons (remote controls, keypads) are programmed for assistance calls.
zone always active where the technical alarm sensors are programmed (smoke, water, gas etc.)
(5000-5002 models only) programming the functions of an additional wired key
(5000-5002 models only) programming wired inputs and connection to zones A,B,C
REMOTE CONTROLS ↑
↵
↵
CONFIRM
MEM. REM. CTRL 01
↵
RED+GREEN KEY
Write the username
of this control
Leave ↵ to stop recording and
listen automatically the message
Now you can escape (ESC),
repeat listening (↵) or erase
(CANC) and repeat recording
VOC. EVEN T 1
↓
24H PANIC AL.
VOC. EVENT 1
↓
MAINS FAILURE
Pressing ↵ to select the function: in this case the message will be sent
following the selected event. For Mains Failure and Periodic Call it will be
program the timing on SETTINGS menu and enable function by turning
Y(yes) the N (no) normally displayed. See instructions for _ _ _ _, _ _ _ _
_ _ _ _ _ / _ _ _ _ _
REM. CONTROL 01 ↑
↵
↵
CONFIRM
↓
Press both the red+green buttons of
the control for programming itself.
VOCAL LABEL
↵
↵ TO RECORD
E
S
C
COPYRIGHT SILENTRON DS5500/1/2/3XB090910GM
↓ ↑
VOC. EVENT 1
↓
24H ROBBERY AL.
↓ ↑
VOC. EVENT 1
↓
PERIODIC CALL
SCAN = radio interference alarm
DISARM = disarming
TAMPER = tampering alarm
REM. 01 ON
↵
↓ ↵
OFF
MEM. 01 ON
↵ MEMOR. OFF
Press ↵ during recording and
look at timing - the total time for
↵
all vocal messages is 240
seconds. (please speak near
microphone)
↓ ↑
↓
↓ ↑
↓
A B C
A B C
A B C
↵
A B C
31
