Start-up
If you are working with a stone wall, drill the
marked two 5 mm holes and insert the plugs
supplied. If you are working with a wooden wall,
you can pre-drill 1.5 mm holes to make screws
easier to insert.
Use the supplied screws and plugs (K) to fasten
•
the mounting plate to the wall (see figure 5).
• Attach the clip-on frame (A) to the mounting
plate.
Place the electronic unit (B) back into the frame
•
(see figure 1). Make sure that "TOP" and the
arrows on the back side point upwards and that
the clips on the mounting plate latch into the
openings on the electronic unit.
5.2.3

Mounting on flush-mounted boxes

You can mount the wall thermostat on flush-mounting/
installation boxes using the holes (I) (see figure 4).
If the device is mounted to a flush-mounting box,
there may be no open conductor ends.
If changes or works have to be made on the house
installation (e.g. extension, bypass of switch- or
socket inserts) or the low-voltage distribution for
mounting or installing the device, the following
safety instruction must be considered:
