Device overview (see figure 1):
(A) Clip-on frame
(B)
Electronic unit (thermostat)
(C)
Display
(D) System button (teach-in button and LED)
(E)
Control wheel
(F)
Mounting plate
Display overview (see figure 2):
Set/actual temperature
Humidity
Warning about condensation
Open window symbol
Battery symbol
Radio transmission
Boost function
Manual operation
Automatic mode
Holiday mode
Heating
