Fix the adhesive strips (G) on the back side of the
•
mounting plate (F) in the provided area. Make
sure that you can read the letters on the back
side (H) (see figure 3) and that the clips on the
mounting plate latch into the openings on the
wall thermostat.
• Remove the protective film from the adhesive
strips.
• Press the assembled wall thermostat with the
back side to the wall in the position where it
should subsequently be attached.
5.2.2

Screw mounting

For mounting the wall thermostat by screws, please
proceed as follows:
• Choose a site for installation.
Make sure that no electricity or similar lines run in
the wall at this location!
• Position the mounting plate (F) on the desired
site on the wall. Make sure that the arrow on the
mounting plate is pointing upwards.
• Use a pen to mark the positions of bore holes (J)
(diagonally opposite) in the mounting plate on
the wall (see figure 4).
• Now drill the bore holes.
