Start-up
If you are working with a stone wall, use a 5 mm drill bit for the wall
plugs supplied. If you are working with wooden walls, you can use a
1.5 mm drill bit to make it easier to screw in the screws.
Use the supplied screws and plugs (K) to fasten the mounting
•
plate to the wall (see figure 5).
Attach the clip-on frame (A) to the mounting plate.
•
Place the electronic unit (B) back into the frame (see figure 1).
•
Make sure that "TOP" and the arrows on the back side point up-
wards and that the clips on the mounting plate latch into the
openings on the electronic unit.
5.2.3

Mounting on flush-mounted boxes

You can mount the wall thermostat on flush-mounting/installation boxes
using the holes (I) (see figure 4).
If the device is mounted to a flush-mounting box, there may be no
open conductor ends.
If changes or works have to be made on the house installation (e.g.
extension, bypass of switch- or socket inserts) or the low-voltage dis-
tribution for mounting or installing the device, the following safety
instruction must be considered:
Please note! Only to be installed by persons with the relevant elec-
tro-technical knowledge and experience!*
Incorrect installation can endanger
• your own life,
• and the lives of other users of the electrical system.
Incorrect installation also means that you are running the risk of serious
damage to property, e.g. from fire. You risk personal liability for personal
injury and property damage.
