Technical Specification; Emissions - Optimum Optidrill B13 Basic Betriebsanleitung

2

Technical specification

Electrical connection
Connection ~50Hz or ~60Hz
Drilling capacity
Drilling capacity in steel [mm]
Throat [mm]
Spindle sleeve stroke [mm]
Spindle seat
Spindle seat
Drilling table
Table size [mm]
Length x Width of the working surface
T-slot size [mm]
Maximum distance [mm]
spindle - table
Working surface stand [mm]
Length x Width of the working surface
Dimensions
Height [mm]
Depth [mm]
Width [mm]
Total weight [kg]
Column diameter [mm]
Speeds
Environmental conditions
Temperature
Relative humidity
Operating material
toothed rod
Drilling column
2.1

Emissions

CAUTION!
The user must wear noise protection and hearing protection.
The A-weighted sound pressure level L
The A-weighted sound power level L
INFORMATION
This numerical value was measured on a new machine under the operating conditions specified
by the manufacturer. The noise behaviour of the machine might change depending on the age
and wear of the machine.
Version 1.0 dated 2019-01-08
B 13 basic
230 V; 300 W
13
104
50
fixed / B16
160 x 160
14
240
135 x 175
580
420
220
19
46

"Speed tables" on page 50
standard plain bearing grease
Acid-free lubricating oil
is 76 to 79 dB.
pA
is 88 to 91 dB.
WA
Translation of the original instructions
OPTIMUM
M A S C H I N E N - G E R M A N Y
B 14 basic B 16 basic
230 V, 350W 230 V, 450 W
14 16
104 125
50 65
fixed / B16 MT2
160 x 160 200 x 200
14 14
330 390
140 x 180 160 x 170
700 820
420 510
230 270
21 36
46 60
535 °C
25 - 80 %
B13 basic | B14 basic | B16 basic
®
GB
Page 43
