Originally released in 1998 and now available again in an up-to-date version with many improve-
ments. The Wingo 2 is one of the best model aircraft for beginners. The Wingo 2 is made of light-
weight EPO foam, making it much more stable and du-rable than the previous version. All of the ori-
ginal wooden parts have been re-placed by plastic molded parts, which simplifies the assembly and
reduces it to on-ly a few hours. The included brushless motor is specially adapted to the Wingo 2 and
gives the model great controllability even at low airspeeds. Both the motor and the speed controller
are pre-wired and soldered ready for installation with plug connections protected against polarity
reversal. The motor and speed con-troller have high power capacities to enable the Wingo 2 to be
used for water starts with Floats (sold separately). Therefore, two different propellers are included
with the model for traditional and water flying. This makes the Wingo 2 the ideal model for beginners
with good-natured flight characteristics and ideally suited for flight training in model flying clubs.
F L I G H T I N S T R U C T I O N S
• Before the first flight, observe the instructions in the „Safety Instructions" section.
• When flying the model, you should choose a day with as little wind as possible
• A large, flat area without obstacles (trees, fences power lines etc.) is suitable for the first flights.
• Please carry out a functional test of the drive train / power set and remote control.
• After assembling the model on the airfield, check once again that all model components such as
wing, tail units, wing mounts, engine, linkages, etc. are firmly and properly fastened.
• For a hand start a helper should be present, who can throw the model with enough thrust into the
air.
• The start usually takes place against the wind.
• Do not stall the model near the ground
• Do not initiate tight turns in the immediate vicinity of the ground.
• Check the reactions of the model to the rudder deflections. If necessary, adjust after landing to
increase or decrease the deflections accordingly.
• The minimum flight speed must be at an adequate safety altitude.
• Initiate the landing with sufficient speed
S A F E T Y I N S T R U C T I O N S F O R R E C H A R G E A B L E B A T T E R I E S
• Do not immerse the battery in water or other liquids.
• Do not heat, throw into fire or microwave.
• Do not short-circuit or charge with reversed polarity
• Do not expose, deform or throw the battery
• Do not solder directly on the battery
• Do not change or open the battery
• Only charge the battery with suitable chargers, never connect it directly to a power supply unit.
• Never charge or discharge the battery or charger on a flammable surface.
• Never leave the battery unattended during charging or discharging processes.
• Never charge or discharge the battery in direct sunlight or near heaters or fire.
• Do not use the battery in places subject to high static discharge.
All this can cause the battery to be damaged, explode or even catch fire!
• Keep the battery away from children
• Keep leaked electrolyte away from fire, as it is highly flammable and may ignite.
• The electrolyte liquid should not get into the eyes, if it does, rinse immediately with plenty of clear
water and then see a doctor.
• The electrolyte liquid can also escape from clothes and other objects with a lot of water or was-
hed off.
• Observe the safety instructions of the battery manufacturer and the charger manufacturer.
P R E F A C E
I N S T R U C T I O N S A N D U S E R M A N U A L
Span 1100 mm
Length 900 mm
Flying weight
ca. 650 g
Wing Area 26 dm²
Airfoil NACA 4408 mod.
C.G.
95 mm
B O X C O N T E N T / N E E D E D A C C E S S O R I E S
Item number Needed accessories
Motor
26560012
ESC
26560013
Battery 7330
Servo ELE
S0009
Servo RUD
S0009
Adhesives 5019
Propeller 26560002
Propeller
26560003
TX -
RX -
Declaration:
LF: Box content
T E C H N I C A L D A T A
Elevator
Rudder
Ailerons
Flaps
Landing flaps
Motor
RO-POWER 2822-23 1450 K/V
RO-CONTROL 22 LITE
RO-POWER ULTRA HP 1100MAH 11,1 VOLT 3S
ROVOR SERVO S0009
ROVOR SERVO S0009
Robbe Speed instant glue set
CARBON SLIM 5/4"
CARBON SLIM 6,5/3,5"
min. 3 channels
min. 3 channels
-
: not included X: included
yes
yes
no
no
no
yes
KIT PNP RTF
LF LF LF
X X X
X X X
- - -
X X X
X X X
- - -
X X X
X X X
- -
X
- -
X
