2. Remove the grilling plates: Press the "eject" buttons at the base and lid of the appli-
ance. Thereafter, carefully pull the grilling plates out of the clamps near the lid hinge.
3. The oil tray could be filled with juices. Pull it out carefully from the left side of the
appliance. Empty the oil tray.
4. Clean the oil tray and the grilling plates in warm dishwater via a soft cloth or soft
brush. You may clean these parts in an automatic dishwasher. In this case, place
the oil tray onto the upper rack.
CAUTION
using the appliance again. Otherwise, residues of food could be burnt to char-
coal, smoke, and even catch fire, when over-heated!
5. Wipe the exterior of the appliance via a moistened, not dripping cloth.
6. While carefully avoiding to drip any liquids into the interior of the appliance, remove
any residues from the heating chambers (below the grilling plates during operation)
via a damp cloth.
7. Thoroughly dry all parts of the appliance after cleaning. Then, leaving the lid of the
appliance open, let all parts dry naturally for approx. 30 minutes, where they are
out of reach of young children and animals.
8. After cleaning, re-assemble the appliance completely and correctly to avoid loss and
damage to the parts (see below: 'Assembling the Appliance').

ASSEMBLING THE APPLIANCE

NOTE
You may interchange the grilling plates by each other as you like. With the gril-
ling plates installed correctly, the grilling plates must be hooked into both clamps
at the rear of the appliance (near the lid hinge). All parts of the appliance can be
installed without applying much force!
9. Installing the grilling plates: Move the lid to the stable upright position. Then, hold the
grilling plate with the juice spout to the rear of the appliance, and slide the notches
in the grilling plate carefully into the clamps near the lid hinge. Then push the front
part of the grilling plate slightly into the base or lid of the appliance for engaging
the lock of the grilling plate with a click.
10. Insert the oil tray in the opening at the left side of the housing and push the oil tray
in to the stop.
11. Close the lid and slide the height control clip to the "LOCK" position. Ensure that
lid and base of the appliance are locked together securely.
– The grilling plates must be completely clean on each side, for
