Keep the machine in safe work condition. Especially
check the fuel system for tightness.
Always remove any dirt from the cooling fins of the
engine.
Residual risks and accident prevention stand-
ards. Neglect of ergonomic principles
Negligent handling of personal protective equip-
ment
Negligent handling or ommission of the personal pro-
tective equipment may cause serious injuries.
– Wear prescribed personal protection equipment.
Human behaviour, misbehaviour
For any work be fully concentrated.
m Residual risks - Cannot be entirely excluded.
Electrical residual risks
Electrical contact
Touching the spark plug may cause an electrical
shock.
– Never touch the spark plug while the engine is run-
ning.
Thermal residual risks
burns, chilblains
Touching of the exhaust/ case may cause burns.
– allow motor driven machines to cool.
Danger from noise
hearing damage
Prelonged unprotected work with the device may
cause hearing damage.
– Always wear ear-muffs
Danger caused by materials and other substanc-
es
Contact, inhalation
The emissions of the machine may cause damages
to health.
– Only use the motor driven machine outdoors.
Fire, explosion
m Fuel is flammable.
– During work and refuelling smoking and open
flames are prohibited.
In case of emergency
In case of a possibly occuring accident take the nec-
essary first aid steps as appropriate and obtain qual-
ified medical aid as quickly as possible.
28 | GB
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
If you obtain aid please give the following infor-
mations:
1. Where did it happen
2. What happened
3. How many injured
4. Type of injury
5. Who is reporting!

7. Technical data

Engine
Transmission
Load capacity
Box length
Box width
Box Depth
Weight
Engine Type
Idle speed
maximum RPM
Motor Starters
Unleaded fuel octane number
Fuel
90 and max. ethanol of 5%
Fuel tank capacity
Required engine oil
Gear oil
Max. slope
Max. oil tank
capacity
Subject to technical modifications!
Noise
m Warning: Noise can have serious effects on
your health. If the machine noise exceeds 85 dB (A),
please wear suitable hearing protection.
Information concerning noise emission meas-
ured according to relevant standards:
Sound pressure L = 84,7 dB(A)
pA
Sound power L = 100 dB(A)
wA
Uncertainty K = 3,0 dB(A)
pA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration Left Steering Lever A
Vibration Right Steering Lever A
Uncertainty K = 1,5 m/s
2
PA
The specified vibration emission value has been meas-
ured according to a standardised testing procedure
and can be used for comparison of one electric tool
with another. The specified vibration emission value
can also be used for an initial assessment of the load.
6,5 PS
3F+1R
300 kg
910 mm
650 mm
575 mm
147 kg
4-stroke engine
1400 1/min.
3600 1/min.
Recoil starter
3,6 l
SAE 10W-30
SAE30 / 80W-90
12°
0,6 l
= 3,92 m/s
2
hv
= 9,92 m/s
2
hv
