Residual risks
• There will always be residual risks, even if you use
this equipment according to instructions. The following
hazards can occur in connection with the construction
and design of this tool.
• Health hazards resulting from swinging of hand and
arm if the equipment is used for an extended period and
if it is not operated or maintained properly.
• Injuries and material damage caused by ejection of tool
attachments which are unexpectedly thrown from the
equipment because of sudden damage, wear and tear
or improper attachment.
• Warning! This tool generates an electromagnetic field
during operation. Under certain circumstances, this
field can affect active or passive medical implants.
In order to reduce the risk of severe or fatal injuries, we
recommend that people with medical implants consult
their doctor and the manufacturer of the medical im-
plant before operating the machine.
• Use the gripping spikes for every cut as the starting
point and always start the cut with the saw chain run-
ning. Make the cut in such a way that the saw does not
get jammed in the wood.
• Pay particular attention to branches under tension.
• Always pull the tool out of the wood when the saw chain
is running.
• Never work with the tool above shoulder height or with
only one hand.
• Always stand away from the falling direction. Position
yourself on a slope above the tree to be felled.
• Always stand sideways when carrying out sawing work
on a tree which is located on a slope, never work from
above or below.
• Always look out for the falling direction of the parts
which are cut off.
• Never start the cut with the bar tip and never cut with
the bar tip.
• Risk of kickback! There is always a risk of kickback
when the bar tip touches the wood or other objects.
This makes the chainsaw uncontrollable and it may be
thrown towards the operator with great force.
• Do not use the tool as a lever to move objects.
• Always use the chain guard during transport and stor-
age.
• Secure the tool during transport in order to prevent loss
of fuel, damage or injury.
• Warning!
• Keep passers-by away from running equipment but
never work by yourself.
• Keep within earshot of others in case you need help.
• Stop the engine immediately when someone approach-
es you.
• Make sure that the saw chain does not come in con-
tact with foreign objects such as stones, fences, nails
and similar. These objects could be ejected and injure
the operator or passers-by or damage the saw chain.
• National specifications may restrict the use of the pole
saw.
• Do not use the machine within 10 metres of a position
from which it can reach high-voltage cables.
Before working on the tool itself (e.g. transport, set-
up, retooling, cleaning and maintenance), discon-
nect the spark plug cap!

6. Technical data

MFH3300-4BP
Technical data
Cutting data grass trimmer
Cutting circle diameter of line mm
Cutting line diameter mm
Cutting line length m
Speed grass trimmer max. min¹
Cutting data brush cutter
Cutting circle diameter of blade
mm
Cutter balde thickness mm
Teeth quantity
Speed brush cutter max. min¹
Cutting data hedge trimmer
Cutting circle diameter mm
Angle adjustment °
Cutting length mm
Max. cutting speed max. min-1
Cutting data pole saw
Bar length mm
Cutting length mm
Chain link thickness
Oil tank capicity cm³
Power unit
Displacement cm³
Max. engine output kW
Fuel tank capicity cm³
Engine type
Idle speed min¹
Weight only power unit kg
Weight grass trimmer kg
Weight brush cutterr kg
Weight pole saw kg
Weight hedge trimmer kg
Subject to technical changes!
Information concerning noise emission measured ac-
cording to relevant standards:
Sound pressure L = 98,2 dB(A)
pA
Sound power L = 112 dB(A)
WA
Uncertainty K = 3 dB(A)
PA
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration
Grasstrimmer: A = Front 3,18 m/s
hv
Brush cutter: A = Front 2,76 m/s
hv
Hedge trimmer: A = Front 3,84 m/s
hv
Pole saw: A = Front 2,79 m/s
hv
Uncertainty K = 1,5 m/s
2
PA
Reduce noise generation and vibration to a minimum!
• Use only equipment that is in perfect condition.
• Maintain and clean the equipment regularly.
• Adopt your way of working to the equipment.
430
2 x 2.4
4
7000
255
1.4
3
8500
24
+90°/0°/-75° (165°)
400
1550
305
254
1.27
125
32.6
0,9
900
2-stroke engine, air-cooled
3000
±200
9,2
11,62
11,52
12,18
12,84
Rear 3,05 m/s
2 2
Rear 3,4 m/s
2 2
Rear 2,0 m/s
2 2
Rear 1,51 m/s
2 2
