TABLE : FAULT DIAGNOSIS

7 Table : Fault diagnosis
8
LED indicator/fault pattern /
LED indicator/fault pattern
Green LED does not light up /
Green LED does not light up
Green LED does not light up /
Green LED does not light up
Green LED does not light up /
Green LED does not light up
Green LED lights up, no output
signal when object is
detected /
Green LED lights up, no output
signal when object is detected
Green LED flashes /
Green LED flashes
Switching outputs not accord‐
ing to graphic C /
Switching outputs not accord‐
ing to graphic C
Switching outputs not accord‐
ing to graphic C /
Switching outputs not accord‐
ing to graphic C
Yellow LEDs flash at the same
time /
Yellow LEDs flash at the same
time
Yellow LED flashes (only
briefly) /
Yellow LED flashes (only briefly)
Cause /
Cause
No voltage or voltage below
the limit values /
No voltage or voltage below
the limit values
Voltage interruptions /
Voltage interruptions
Sensor is faulty /
Sensor is faulty
Test input (TI) is not con‐
nected properly /
Test input (TI) is not con‐
nected properly
IO-Link communication /
IO-Link communication
IO-Link communication /
IO-Link communication
Parameter settings made
manually, which deviate from
the standard /
Parameter settings made
manually, which deviate from
the standard
The sensor is not ready for
operation. The sensor will be
in the warming-up phase at
low ambient temperatures.
The sensor will have shut
down at excessively high
ambient temperatures. /
The sensor is not ready for
operation. The sensor will be
in the warming-up phase at
low ambient temperatures.
The sensor will have shut
down at excessively high
ambient temperatures.
Teach-in mode /
Teach-in mode
Measures /
Measures
Check the power supply,
check all electrical connec‐
tions (cables and plug connec‐
tions) /
Check the power supply,
check all electrical connec‐
tions (cables and plug connec‐
tions)
Ensure there is a stable power
supply without interruptions /
Ensure there is a stable power
supply without interruptions
If the power supply is OK,
replace the sensor /
If the power supply is OK,
replace the sensor
See the note on connecting
the TI /
See the note on connecting
the TI
-
-
Initiate a factory reset. The
switching outputs are reset to
factory settings. /
Initiate a factory reset. The
switching outputs are reset to
factory settings.
At low ambient temperatures,
wait until the sensor has
warmed up. Ensure the sensor
cools down at excessively high
ambient temperatures. /
At low ambient temperatures,
wait until the sensor has
warmed up. Ensure the sensor
cools down at excessively high
ambient temperatures.
Check the teach-in mode /
Check the teach-in mode
