8

Disassembly and disposal

9

Maintenance

10

Technical data

Laser class
Sensing range
Sensing range max.
Light spot diameter/distance
Supply voltage V
S
Output current I
max.
Max. switching frequency
Max. response time
Enclosure rating
Protection class
Circuit protection
8018110.ZM26 | SICK
Subject to change without notice
LED indicator/fault pattern /
LED indicator/fault pattern
Yellow LED lights up, no object
in the path of the beam /
Yellow LED lights up, no object
in the path of the beam
Object is in the path of the
beam, yellow LED does not
light up /
Object is in the path of the
beam, yellow LED does not
light up
The sensor must be disposed of according to the applicable country-specific regula‐
tions. Efforts should be made during the disposal process to recycle the constituent
materials (particularly precious metals).
SICK sensors are maintenance-free.
We recommend doing the following regularly:
• Clean the external lens surfaces
• Check the screw connections and plug-in connections
No modifications may be made to devices.
Subject to change without notice. Specified product properties and technical data are
not written guarantees.
-Bxx3x -Bxx4x
1 1
100 ... 2500 100 ... 1800
mm mm
1 1
50 ... 2500 50 ... 1800
mm mm
1 1
< 14.0 mm / < 12.0 mm /
2500 mm 1800 mm
DC 10 ... 30 DC 10 ... 30
V V
2 2
≤ 100 mA ≤ 100 mA
1,000 Hz 30 Hz
3 3
0.5 ms 16.7 ms
4
IP 67 IP 67
III III
A, B, C A, B, C
5
DISASSEMBLY AND DISPOSAL
Cause /
Cause
/ Distance between the sen‐
sor and the background is too
short /
/ Distance between the sen‐
sor and the background is too
short
Distance between the sensor
and the object is too long or
sensing range is set too
short /
Distance between the sensor
and the object is too long or
sensing range is set too short
-Bxx6x -Bxx1x
1 1
100 ... 3800 100 ... 1600
mm mm
1 1
50 ... 3800 50 ... 1600
mm mm
1 1
< 18.0 mm / < 11.0 mm /
3800 mm 1600 mm
DC 10 ... 30 DC 10 ... 30
V V
2 2
≤ 100 mA ≤ 100 mA
100 Hz 1000 Hz
3
5 ms 0.5 ms
4 4
IP 67 IP 67
III III
A, B, C A, B, C
5 5
Measures /
Measures
Reduce the sensing range,
see graphic F /
Reduce the sensing range,
see graphic F
Increase the sensing range,
see graphic F /
Increase the sensing range,
see graphic F
-Bxx2x -Bxx5x
1 1
100 ... 1400 100 ... 1800
mm mm
1
50 ... 1400 50 ... 1800
mm mm
1
<10.0 mm / < 12.0 mm /
1400 mm 1800 mm
DC 10 ... 30 DC 10 ... 30
V V
2 2
≤ 100 mA ≤ 100 mA
30 Hz 100 Hz
3 3
16.7 ms 5 ms
4 4
IP 67 IP 67
III III
A, B, C A, B, C
5 5
8
1
1
3
4
5
9
