JO-DataClient - Terminal software for CHM15k
Below there is a button named "auto transfer off". Pressing this button
means, that all previous automatic transfer modes will be cancelled.
The next block contains three buttons for single telegram acquisitions:
– small: The standard data telegram is requested, see user guide, section
– large: The advanced data telegram is requested, see user guide, section
– all: The raw data telegram is requested, see user guide, section 8.2.4.
The next block contains three buttons for automatic polling of data tele-
grams.
Below there is an input field for the internal measure period (in seconds) of
the CHM15k. The associated button must be pressed, if this value should go
into effect for the CHM15k device. Nevertheless, this value is also used as
the time between automatic polling mode acquisitions described in the
previous paragraph, and changes of the value in this sense are applied
without pressing the button "set measure period"!
The next block contains three buttons for automatic telegram output,
initiated by the CHM15k itself, i.e., not by polling.
Remark: All six automatic telegram modes will be cancelled by pressing the
button "auto transfer off", or also by acquisition of one of the three single
telegrams.
Now a block follows for reading and writing internal CHM15k parameters:
– device variable: Here the name of the concerning CHM15 parameter has
– set value: Value for the "send set command".
– send get command: The current value of the parameter is displayed in
– send set command: Value "set value" is transmitted to the CHM15k. Pro-
– switch "auto clean of input fields": If activated, the two input fields
56
8.2.2.
8.2.3.
to be specified. A summary of these parameters can be find in the user
guide, tables 4 and 16.
the box "CHM15k answer" on the right side.
vided that the suitable parameter is really alterable and is in the permissi-
ble range, the successful parameter update will be acknowledged in the
box "CHM15k answer". If one of these restrictions is violated, there is no
acknowledgement and the parameter is not changed. For safety reasons
some of the parameters are alterable only in the service mode, see user
guide, section 8.6.
"device variable" and "set value" will be erased after each set or get
command
