Technical Data

Voltage
Motors three phase
Saw diameter min.-max.
Max. depth of cut (dia. 400 min)
Max depth of cut at 45°
Tilting of main saw
Max. cut capacity on right side
Saw stroke
Saw arbor diameter
RPM main sawblade
Motor power scorer
RPM sawblade scorer
Scorer diameter
Max depth of cut incisor
Tilting of scorer
Sliding table dimensions
Saw table dimensions
Diameter outlet
Net weight
Gross weight
Packing dimensions (LxWxH) Z3200
Packing dimensions (LxWxH) Z2500
Packing dimensions (LxWxH) Z1700
Z3200 10-V0713
V 220 - 380 - 220 mono
KW 4-5,5, Option 7,5
mm 300-400
mm 125
mm 100
90° - 45°
mm 1380
mm 3200-2500-1700
mm 30
3000-4000-5000
KW 0,5
7000
mm 120
mm 4,5
90° - 45°
mm 3200-2500-1700x400
mm 1530x700
mm 120 - 60
Kg 1150-1050-1000
Kg 1200-1100-1050
mm 2270x1330x1020
+ 3250x450x200
mm 2270x1330x1020
mm 2270x1330x1020
