5. Device description

5.1 Versions

If a servomotor is ordered together with a dosing
pump, the servomotor is fitted onto the pump at the
factory and subjected to a function test. Once on
site, qualified specialist staff must establish the
relevant electrical connection.
Servomotors can also be supplied for retrofitting on a
dosing pump, together with the necessary mounting
material. Such servomotors also undergo testing at
the factory prior to delivery. Qualified specialist staff
must fit the servomotor onto the dosing pump and
establish the electrical connection.

5.2 Variants

5.2.1 Variants according to pump type
For DMX 221
• 1 servomotor for single pump
For DMX 226, DMH 25x/28x
• 1 servomotor for single pump
5.2.2 Control variants
• With analogue control 4 (0) - 20 mA
5.2.3 Versions, servomotor product numbers and corresponding pump types
A servomotor kit includes servomotor and mounting material. A spare servomotor is delivered without
mounting material.
Servomotor for pump type
DMH 251-257,
384-511
DMH 280-288
DMH 251-257,
384-511
DMH 280-288
384-711 DMX 221
384-711 DMX 221
384-712 DMX 226L
384-712 DMX 226L
384-715 DMX 226M
384-715 DMX 226M
6
Pump
type key, Servomotor
control kit
variant
D3 95721977
D4 95736296
D3 95725108
D4 95736495
D3 95725109
D4 95736497
D3 95725666
D4 95736504
Spare
Power supply
servomotor
98721200 115-230 V, 50/60 Hz
98721222 24 VDC, 50/60 Hz
98721200 115-230 V, 50/60 Hz
98721222 24 VDC, 50/60 Hz
98721200 115-230 V, 50/60 Hz
98721222 24 VDC, 50/60 Hz
98721200 115-230 V, 50/60 Hz
98721222 24 VDC, 50/60 Hz
Control
variant
analogue
control
analogue
control
analogue
control
analogue
control
analogue
control
analogue
control
analogue
control
analogue
control
