8.3 Installation

Warning
Never install a damaged drive.
Observe the installation and operating
Note
instructions for the dosing pump.

8.3.1 General notes on installation

• Remove any anti-corrosion agent (that may have
been used for storage purposes) and apply
grease instead.
• Check the cable entries and dummy plugs for
tightness.
• Tighten the hood screws so they are all equally
tight.
• Protect the drive from the effects of the weather
(by means of a canopy, for example).
• Do not attach any ropes, hooks or similar directly
to the drive.
• Continuously overloading and blocking the drive
will damage it.
• Spark-quenching capacitors may adversely affect
the drives' direction of rotation stability and result
in damage.
Cable entries
• When storing, installing and commissioning the
servomotor, care must be taken to ensure that
the cable entries have been properly sealed.
Only cables appropriate for the diameter of the
cable entries must be used.
Installing the hood
• When installing the hood, you must ensure that
the O-rings underneath the hood screws and the
O-ring in the drive housing are properly seated.
• The connection face of the hood must not show
any signs of damage.
• Tighten the hood screws equally.
Housing/Hood
• No additional bores may be drilled into the drive
housing or the hood.

9. Electrical connections

9.1 General warnings and notes on the
electrical connection
Observe the supplier manual "TBasic_BA" for the
servomotor provided with the product.
Warning
Electrical connections may only be
established by qualified staff.
Before opening housing, disconnect the
servomotor from the power supply.
Observe the local safety regulations.
Protect the cable connections and plugs
from corrosion and moisture.
Warning
The applicable regulations must be
observed when carrying out electrical
installation and commissioning work.
Warning
Protective measures must be put in place
in accordance with the relevant VDE
guidelines and power supply company
regulations. In particular, VDE guideline
0105, "Working on live installations", must
be taken into account.
Warning
All elements, such as switch cams,
switches, potentiometers, relays, etc., are
wired at the factory. The internal wiring
must never be modified.
Warning
The terminals at the limit switches are live
when the switch closes.
Warning
The following must be taken into account
for explosion-protection servomotors and
pumps.
Danger of explosion!
Only use high-strength cable glands
appropriate for the cable size.
Attach suitable caps to unused openings.
Switch cams and limit switches are set at
Caution
the factory and must not be modified.
Before connecting the mains cable, check
whether the type of current, the supply
voltage and the frequency stated on the
Caution
type plate match the local conditions.
An incorrect supply voltage may destroy
the servomotor.
