29. MIDI Implementation OctaMic XTC

29.1 Basic SysEx Format

Value
F0h
00h 20h 0Dh
69h
00h..7Eh, 7Fh
mm
nn
F7h

29.2 Message Types - Commands

Value
10h
11h
012h
020h
30h
Request Value
Format: F0 00 20 0D 69 (dev ID) 10 F7
This string triggers a complete dump of all parameter data bytes.
Value Response
After being triggered by receiving a request parameter command, device sends a string of all
parameter data bytes. Message type is set to 30h.
Set Parameter
Sets any number of parameters.
mm / nn can be repeated freely.
Request Level Meter Data
Format: F0 00 20 0D 69 (dev ID) 11 F7
This string triggers a dump of the level meter data.
0xf0, 0x00, 0x20, 0x0d, 0x69
MIDI device ID, command ID, parameter index, parameter LSB, parameter MSB, set-flags, ...,
0xf7
(... = multiple parameters per message allowed, each consisting of index, LSB, MSB, set-flags)
Set-flags: set to value from list to set the according parameter in the device, otherwise parame-
ter will be ignored. Set-flags are only assigned for commands containing multiple parameters.
Messages sent by the device (command ID 0x30) do not contain set-flags.
Example for MIDI device ID 0
f0 00 20 0 69 00 20 01 1c 08 7f 0a 30 10 0d f7
Set Gain Mic 2 to 37dB; Pad on; Phase-Invert, Mute, AutoSet, 48V off; all parameters to be set.
Set Phones 1 source to MADI1/2; high Level, Phase-Invert off, Mute not to be set.
72
Name
SysEx header
MIDITEMP manufacturer ID
Model ID (OctaMic XTC)
MIDI device ID
Command ID
Data (parameter index, parameter LSB, parameter MSB, set-flags, ...)
EOX
Name
Request value
Request level meter data
Request changed parameters
Set parameter (multiple parameters allowed)
Send parameters (multiple parameters allowed)
