29.3 Tabelle

Commands
ID Command
0x10 request all parameters (incl. level data)
0x11 request level data
request changed parameters (in case of no changes: empty
0x12 block)
0x20 set parameter (multiple parameters allowed)
0x30 send parameters (multiple parameters possible)
Parameters
Index Value
0 Channel Settings Mic 1 (see Details below)
Channel Settings Mic 2
1
2 Channel Settings Mic 3
3 Channel Settings Mic 4
4 Channel Settings Mic 5
5 Channel Settings Mic 6
6 Channel Settings Mic 7
7 Channel Settings Mic 8
8 Phones 1 Volume (see Details below)
9 Phones 1 Balance
10 Phones 1 Settings
11 Phones 2 Volume
12 Phones 2 Balance
13 Phones 2 Settings
14 Digital Routing ADAT Out, ADAT2 Out (see Details below)
15 Digital Routing AES Out
16 Digital Routing MADI 1-8, MADI 9-16
17 Digital Routing MADI 17-24, MADI 25-32
18 Digital Routing MADI 33-40, MADI 41-48
Digital Routing MADI 49-56, MADI 57-64
19
20 Digital Routing Rec. 9-16, Rec. 17-24
21 Clock Settings
Bit 0-3: Clock Source (internal, WCK, AES1..AES4, ADAT,
LSB MADI)
Bit 4: WCK always single
Bit 5: WCK termination active
Bit 0-3: Sample rate index (32k, 44.1k, 48k, 64k, 88.2k, 96k,
MSB 128k, 176.4k, 192k)
22 MADI Settings
Bit 0-1: Delay Compensation (0-Off, 1-Manual, 2-Auto-ID, 3-
LSB Auto CA)
LSB Bit 2: MADI-Format (0: 56ch, 1: 64ch)
LSB Bit 3: MADI-Frame (0: 96k, 1: 48k)
MSB Bit 0-2: Delay Compensation ID (0-7 for ID 1-8)
